Place of Origin: | CHINA.QINGDAO |
Brand Name: | WEIER |
Certification: | SGS,CE |
Model Number: | SJSZ-92/188 |
Minimum Order Quantity: | 1 SET |
---|---|
Price: | 120000-135000USD |
Packaging Details: | export package |
Delivery Time: | 55 days |
Payment Terms: | TT |
Supply Ability: | 50 sets per year |
Highlight: | wpc foam board machine,wpc production line |
---|
Wood Plastic Composite WPC Board Production Line , CE Certificate SJSZ-92 / 188
Quick Detail:
Wood plastic door panel production line
1. Special design mould
2. PLC control system
3. CE and ISO9001 certification
4. Advanced newest technology
Description:
It adopts the special designed screw, to produce plastic and wood composite products to produce wide door plate, wide panel. Wood-plastic composite products from polyolefin plastic and fiber (straw, wood flour, rice bran) After special processing means made of a new type of environment protection material, manufactured products would not rot, deformation, color legs, and rejected pests, not cracking, and maintenance of fire safety without the advantages of good performance, plastic and wood from the respective merits can be made railings, trails, outdoor furniture, office furniture, furniture, logistics, packaging, trays, and much more. The line profiles can be based on different sections and die, the parallel use of different specifications (cone) twin-screw extruder, and the corresponding equipment are Vacuum Calibration Unit, Hole Punching Machine, Haul-off Machine, Saw Type Cutter, Stacker and etc.
The machine can produce PE, PP or PVC and wood profile products. These products are mainly applied for making pallets, packing cases, floors, wall decoration materials and other wide applications. The wood powder or plant fiber can be put up to max. 30-65%.
Applications:
Commercial residential building, house & villa,hotel,office building,school,hospital,etc. (specially used the large temperature difference,damp,poorly ventilated places.
Specifications:
Item |
SJSZ 65/132 |
SJSZ 80/156 |
SJSZ 92/188 |
Screw Diameters(mm) |
65mm/132mm |
80mm/156mm |
92mm/188mm |
Output(Kg/h) |
160-200 |
250-350 |
400-650 |
Main Driving Power(kw) |
37 |
55 |
110 |
Heating Powder(Kw) |
4 zones, 20Kw |
5 zones, 42Kw |
6 zones, 58Kw |
Our Company Service:
Pre-sale service:
•Plant Planning: We provide the mounting dimension of the equipment base,design of equipment layout, workshop ventilation, water transmission etc.
In-sale service:
• Detailed design of lay-out that is the position of the procession
• Technological information of provided products
• Schedule about design,manufacturing and installation
• Working & Producing progression
•Training course for the technician so that the installation is safe and standard
After-sale service:
•we provide free training so that they can use and maintain the machine independently.
•We will answer customer's question on technology in time. If needed, we will offer on-site guidance and assistance.
•We can provide free technical guidance if customers need new equipment, add or rebuild equipment.
WPC door is made from PVC resin and good quality wood powder, And with 5% of
fertilizer, molding at the condition of high temperature,high pressure and vacuum. The
surface adopt heat transfer printing or pro-environment paint. The material of WPC has no
formaldehyde. So there is no toxic and harmful gases released when manufacture and
use. It is the one which meet the environmental protection standard of modern interior
decoration. Colorless difference,not cracking,wear resistant,damp proof,corrosion
resistant,sound insulation,beauty,luxurious, It is the first choice of green environmental
protection product which used for household furniture and engineering.
WPC door structure
A .One-step molding, with no flat-fell seam ,no edge, no cracking deformation.
B.with 4cm rib and wooden fill, thickness plate
C .Bayonet type cover, easy installation, save time and labor, simplify processing.
D .Cellular structure and cavity type with good buffer and sound insulation.
Product features:
Environmental protection property: no formaldehyde and other harmful substances
Waterproof: professional waterproof, germicide and mold proof, anti-corrosion,mothproof
Practical: no warping,no wood knots & twill, can be nails,drilling, cutting.
Safety: fireproof(oxygen index is 48,fire rating with B1),sound insulation and heat insulation.
Aesthetic: modern stylish,beauty, various styles.
