Higher performance cemented disc cutter for plastic cutting

Higher performance cemented disc cutter for plastic cutting

  • Higher performance cemented disc cutter for plastic cutting
Higher performance cemented disc cutter for plastic cutting
Product Details:
Place of Origin: Zhuzhou
Brand Name: none
Certification: ISO9001:2008 ,ISO14001:2004
Model Number: many
Payment & Shipping Terms:
Minimum Order Quantity: 10 pcs
Price: negotiation
Packaging Details: plastic box, brown paper box, Blister packing,wooden case
Delivery Time: 15-25 days
Contact Now
Detailed Product Description
Model Number:: Various Chemical Composition:: WC, Co
Grade:: YG6 YG6X YL10.2 Ect
High Light:

Tungsten Carbide blade

,

carbide rotary cutter

Higher performance cemented disc cutter for plastic cutting









Description:.



tungsten carbide disc cutter usually is machined into all kinds cutter with tooth,tungsten carbide lead wire cutter with excellent hardness and abrasive resistance.

1.   the thickness can reach 0.5mm for unground disc cutter.
2.   Sintere by vacuum sintering furnace and HIP machine with excellent specifications without any hole.
3.   can suply unground cutter or process according drawing,such as grinding face,outdiameter,innerhole,punching,making slotting,blade or teeth ect.
4.   Suitable for machining hardened steel, alloy steel, cast iron, non-ferrous metal, stainless steel, high manganese steel, plywood, PCB, PVC, electronic board.



Properties and applications of carbide for discs

Grade Density T.R.S MPa

Hardness

 HRA

Performance &

application recommended

YG6A 14.95 1800 92.5

Fine grain alloy, good wear resistance.

Semifinishing of chilled

 cast iron, non-ferrors metals alloys,

semi-finishing and finishing

 of hardened steel, alloy steel.

YG8 14.8 2200 89.5

High strength in use, impact and shock

resistance higher than

YG6, but wear resistance and cutting

speed comparatively lower.

 Roughing of cast irons, non-ferrors

metals and their alloys as well

 as non metallic materials at low cutting speed.

YG10X 14.5 2400 91.5

Fine grain alloy, good wear resistance.

Used for processing hard

wood, veneer board, PCB, PVC and metals.

YL10.2 14.5 2400 91.8

Fine grade alloy, with high wear resistance,

high bending strength,

 high resistance to bonding, high thermal

strength. Machining of

 refractory alloys, stainless steel and high

manganese steel, etc.

G20 14.3 2420 90

Conventional wear resistance,

high bending strength, used for steel

alloy etc.

Other grade of disc may be offered according to customers' requirement



 Types of discs



unit:mm
TYPE D d S
Φ12×Φ6×S 12 6 0.6-4.5
Φ13×Φ6×S 13 6 0.6-4.5
Φ16×Φ6×S 16 6 0.6-4.5
Φ22×Φ10×S 22 10 0.6-4.5
Φ25×Φ12×S 25 12 0.6-5.5
Φ32×Φ10×S 32 10 0.8-5.5
Φ40×Φ10×S 40 10 0.8-6.0
Φ45×Φ13×S 45 13 0.8-6.0
Φ53×Φ13×S 53 13 0.8-6.0
Φ52×Φ24.5×S 52 24.5 0.8-6.0
Φ53×Φ24.5×S 53 24.5 0.8-6.0
Φ55×Φ16×S 55 16 0.8-6.0
Φ58×Φ22×S 58 22 0.8-6.0
Φ60×Φ19×S 60 19 0.8-7.0
Φ63×Φ17×S 63 17 0.8-7.0
Φ70×Φ22×S 70 22 0.8-7.0
Φ75×Φ22×S 75 22 0.8-7.0
Φ80×Φ22×S 80 22 0.8-7.0
Φ83×Φ21×S 83 21 0.8-7.0
Φ86.5×Φ21.5×S 86.5 21.5 1.0-7.0
Φ90×Φ22×S 90 22 1.0-7.0
Φ100×Φ22×S 100 22 1.0-7.0
Φ125×Φ22×S 125 22 1.0-7.0
Φ200×Φ70×S 200 70 3.0-4.5
Φ250×Φ70×S 250 70 3.0-4.5
Φ250×Φ95×S 250 95 3.0-4.5





Zhuzhou Mingri Cemented Carbide Co., Ltd is professional manufacturer in tungsten carbide axle sleeve,

seal ring,  spool, valve seat, molds, square sheets, boards, rolls, inserts, depth drills, saw tips, slitter blade,

thin blade, leather blade, punching molds, decorations, nozzles, pipe, plunger, mill roller and all kinds of

non standard parts. The company is located in Zhuzhou city which is boasted as the City of Tungsten

Carbide. Based on the  ISO9001:2008 ISO14001:2004  quality assessment system, the expertises has

 been operating more than 40 processing machines to meet the production needs. Under the supervising

of the professional technicians who are honored for the state council special allowance, we have succeeded

 in solving all kinds of problems which could happen during producing the complex non standard parts, and

gained a good reputation from home and abroad.



PRODUCT FEATURES

 1. Grades can be designed according to your requirements and stone diversity. Our engineers

provide helpful suggestions for you.

 2. 100% precise raw material makes longer using life.

 3. Precise molds produce products with more accurate dimension.

 4. Strict products filtering ensure reaching to qualified standard.

 5. Enhancement of processing reduced inferior products, increased wear  resistance.

 6. Full selections of types, grades, sizes available, decreasing your cost and shortening delivery time.





Higher performance cemented disc cutter for plastic cutting 0
Company Profile


Zhuzhou Mingri Cemented Carbide Co., Ltd.



Located in Liyu Industrisl Area, Zhuzhou City, Tianyuan District, Hunan Province, Zhuzhou Mingri Cemented Carbide Co., Ltd was established in May of 2001 with the investment of RMB 40 million. We own up-to-date production line, advanced equipment, lots of technicians. We have passed ISO 9001:2008,ISO 9001:14001. And we have been always trying our best to provide our customers with high quality , best price and satisfactory services.






We specialize in series of tungsten carbide products, such ascold forging die cores, brazed tips, disc cutters, plates and boards, saw tips, round rods, rock drilling bits and buttons, milling tools, geological exploration drill tools and so on. Our production are exported to UK, European, Japan, Taiwan and South-east Asia etc.



You` re welcome to have a visit to our factory!






All varieties

Provide a comprehensive stamping precision metal strip material, gradually precision stamping one-stop shopping;
Provide comprehensive domestic and imported grades of metal strips of different products to meet the needs of different customers and different quality.

Quick delivery

200 tons of standing stock to ensure adequate supply;
6 precision sub-production lines run 24 hours;
Taiwan vans at you life, deal with the urgent needs of our customers.



Good service

18 professional sales engineer to provide a full range of alloy selection of technical and sales support materials;
Minimum quantity, flexibility to meet customers needs at different stages.



Excellent quality

Through ISO9001: 2008 quality system and ISO9001: 14001 Environmental System Certification;
Hunan, with all the most advanced testing equipment, strict quality control for the customer;
Customized ERP sophisticated control systems, strict to ensure the production, delivery accuracy.



Improve marketing and service network
The company's marketing and service network all over the country, the product quality by the majority of users praise. Including in Europe and the United States, including the permanent sale of the company's overseas sales network covering more than 70 countries worldwide, products are exported to all continents.
